Flatbeds & Canopies
We build custom flatbeds and canopies for any bakkie on the market. Every one is shaped for the vehicle it goes on, because each bakkie is a different size and style.
6YR
Workmanship warranty
On your tray and canopy. Whether it is used for work or leisure, we stand behind the product and back it up with after sales service. That is what your investment is buying beyond the way it looks.
Hand built, made to order
The flatbed tray
Everything is modular, so changing or maintaining your vehicle stays easy. The toolboxes, the centre drawer and the floor panels all come out. Trays come standard with modern LED lights, plus built-in spotlights wired either to reverse gear or to a switch in the cab.
The drawer in the middle of the tray is waterproof and locks with a key, and so do the toolboxes behind the wheels.
What you get
- Hand built, made to order, for your vehicle
- Fully welded and sealed custom steel tray chassis
- 2mm steel one-piece mudguards, everything else aluminium
- Two CAD-designed under-tray tapered aluminium toolboxes with flush push locks
- Lockable waterproof aluminium centre drawer that doubles as a work table
- Removable checker-plate (vastrap) aluminium flooring
- Imported flush-mount LED combination tail lights
- Flush-mount LED reverse flood lights
- Orange indicator light on each side
- Built-in spotlights wired to reverse or a switch in the cab
- 8mm rubber mudflaps on stainless steel hardware
- Vehicle-specific chassis mounts - no universal mounting attachments
- Sandblasted, welds seal-seamed, acid primed, MS primed, then painted
- All stainless steel mounting hardware where applicable
Flatbed optional extras
- Colour-coding to your vehicle
- Double walled 3mm aluminium drop-sides
- Built-in ARB air compressors
- Toolbox interior lights
- Back board with built-in 45L water tank
- Stainless steel tray protector
Custom shaped per model
The standard canopy
A completely TIG welded, custom shaped canopy designed to suit each model vehicle. The aluminium body is laser-cut, bent, and fully TIG welded around a tubular frame with additional interior structure support, which is what makes the canopy chassis strong enough to carry a rack or a tent.
What you get as standard
- Custom shaped per vehicle model - each bakkie is a different size and style
- Fully TIG welded tubular frame with interior structure support
- Laser-cut and bent aluminium body, TIG welded around the frame
- Flush fitting recessed gullwing doors with internal structural support
- Two flush-mount stainless steel locks per door
- Pneumatic gas struts - doors open flush with the canopy roof
- Waterproof door hinges, so no water enters when the doors are open
- Heat reflecting paint for cooler internal temperatures
- Extra roof support and customer-specific mounting points for racks and tents
- Two interior lights
- Provision for lift-off legs
- Painted professionally in black as standard
The in-betweener
Dogbox canopy
The perfect balance between enclosed and open packing space. Our dog boxes make sure your furry best friend is able to conquer the outdoors by your side, where they should be.
As with everything else we build, dogboxes are made to your exact requirements — and it does not have to be for an animal. The other side can be fitted with any accessory you want, like your camping fridge.
No roof rack needed
Roof top tent canopies
The roof of the canopy becomes the floor of the tent, so all that gets added is the clamshell roof. That saves you the extra height, the extra weight and the cost of a roof rack.
The tents are built for any season and any condition. Insulated, with extra supports in the roof so fitting a rack or mounting solar panels is safe and easy, and a 7cm high density foam mattress.
Canopy optional extras
Your stock standard vehicle arrives at our workshop and leaves Africa ready. We complete the majority of the upgrades in house.
- High gloss 2pac colour-coded to your vehicle
- Colour-coded or aluminium internal dividers
- Removable and adjustable spare wheel carrier
- Jerry can and gas bottle carriers
- Removable stainless steel or aluminium fold-out ladders
- Removable canopy roof rails
- Exterior and interior door molle panels
- Two kitchen options
- Two pull-out pantry options
- Multiple drawer systems
- Standard and custom electronic packages
- Built-in air compressors
- Stand-up fridges
- Central locking
- Multiple water tank sizes
- Roof mounted slide-out tables
- Fold-out shower and pull-out geyser
- Solar panels
- 270° awning
What are you building?
Send us the vehicle, what you tow, and what you need to carry. We design the interior around how you actually use it.
